Thread cutter module
Modules
Disassembly
1
Thread cutter frame assembly removal
1.
Remove the 2 screws
1
, and then remove
the thread cutter fram
e assembly
1
, 2 collars
2
, and polyester slider
3
.
2.
Remove the wave-sha
pe spring washer
4
.
1
1
2
2
3
4
2
Photo transistor assembly removal
1.
Remove the 2 screws
1
, and then remove the photo transistor assembly
1
.
1
1
3
Presser plate removal
1.
Remove the screw
1
, and then remove the
presser plate
1
and spring
2
.
1
1
2
75
77
