BACA SYSTEMS BOSS - Machine Functionality; Single Cut Operation Guide; Multiple Cuts Procedure

BOSS Saw User Manual V1.0
5/9/2019
13
Functionality
Single Cut
1. Select Single Cut
2. You must position the head exactly where and how you want it to start cutting
3. There are 3 ways to set the cutting limits
a. 2 point (precise)
i. Start
ii. Move the head where you want the cut to end
iii. End
b. Length
i. Length
ii. Type desired length in Length box
iii. Press Enter
c. Through
i. If slab is defined, it will apply the cut all the way through the slab
4. In either case, a cut should appear. If you get any kind of alarm, something is not satisfied.
5. Menu
6. See SEND PROGRAM for further instructions
Multiple Cuts
1. Select Multiple Cuts
2. You must position the head exactly where and how you want it to start cutting
3. There are 3 ways to set the cutting limits
a. 2 point (precise)
i. Start
ii. Move the head where you want the cut to end
iii. End
b. Length
i. Length
ii. Type desired length in Length box
iii. Press Enter
c. Through
i. If slab is defined, it will apply the cut all the way through the slab
4. In either case, a cut should appear. If you get any kind of alarm, something is not satisfied.
5. Pieces number= Number of pieces you want at that size
6. Piece Width= How wide do you want that piece
a. the cuts should update as you change the information
