BOSS Saw User Manual V1.0
5/9/2019
Tilt Table
From the main screen
1. Lift stop plates up on table
2. Press START PROGRAM
3. Press Table Up
a. The machine will park, the pump will start, and the table will lift
b. The pump will stop once table is all the way up
4. Set pressure treated 2x4 on stop plates
5. Place stone on 2x4
Be sure that no one and nothing goes behind the table while it is in the UP position!!
Lowering the Table
Be sure everyone and everything is clear from behind the machine
Press Table Down
The pump will start, the table will lower, and then the pump will turn off automatically
