BACA SYSTEMS BOSS - Spare Parts List; Critical Spare Parts Inventory

BOSS Saw User Manual V1.0
5/9/2019
35
Minimum Spare Parts List
Part Description Axis QTY to Order Part Number (R #)
Jaw Coupling Insert Y 5
Ball screw nut oil seal Y 10
Ball screw nut O-ring (small) Y 10
Ball screw nut bearing Y 20
Ball screw nut O-ring (large) Y 20
Linear bearing block Y, X, Z 60
Belt Y 10
Belt X 5
Ball screw nut oil seal X 5
Ball screw nut O-ring (small) X 5
Ball screw nut bearing X 10
Ball screw nut O-ring (large) X 10
Tilt table hard stop screw N/A 40
**INSERTED CRITICAL PARTS LIST INFO HERE - SUBJECT TO CHANGE**
