BACA SYSTEMS BOSS - Wireless Pendant Usage; Wireless Pendant Controls and Functions

BOSS Saw User Manual V1.0
5/9/2019
30
Using the Wireless Pendant
1. Press JOG/Shift twice
a. Wait 3 seconds
 All buttons other than JOG/Shift have 2 positions
o Half press (HP)
 Cutting feed-rate
 Special (when combined with another button)
o Full press (FP)
 Rapid travel
 Second function
Raise Blade Lower Blade
Reverse Cut Direction Forward Cut Direction
Against Blade Against blade
Rotate Left Rotate Right
Spindle/Water ON Water/Spindle OFF
Start Pendant/JOG Mode
Auto Mode/Park
Any Arrow
Half Press
Full Press
Precise Movements
Rapid Moves
Vacuum Lift
Vacuum lower
+90 Degrees
-90 Degrees
Cutting Speed/Special function
