BOSS Saw User Manual V1.0

5/9/2019

Extend Cuts

1. Select EXTEND CUTS

2. click the side of the line you want to extend

3. Select STRETCH

4. Left click and drag it to where you want the BOTTOM of the cut to stop.

5. Repeat as needed

6. THROUGH- extends both sides of that line to the defined edges of the slab

Machining

1. MACHINE PIECES

 This should only be used if you need to process the entire sink. Or for some reason the Piece Cuts page could not

process something

2. Click on the object you want to process. A complete shape will turn green

a. Be mindful of the green arrow. This will be where the lead in and out will be applied.

If you only want to process only a certain section, double click on it until the ren and green thumbtacks appear. Then

you can drag the thumbtacks where you want the process to start and stop

3. Profiles
