BACA SYSTEMS BOSS - Square Cut Functionality; Square Cutting with Slab Defined

To Next Page

To Previous Page

BOSS Saw User Manual V1.0

5/9/2019

Square

1. Select Square

 This screen will have different options depending on if you have defined the slab or not

1. Slab Defined

 The head does not need to be positioned

a. ADD

b. Piece Width= Width of pieces

c. Piece Length= Length of pieces

d. Piece Angle= affects vertical cuts only

e. Piece Number= is filled in automatically by how many it can cut

f. X Position= adjustment left or right

g. Y Position= adjustment up or down

h. Cut Angle= changes the rotation of all the pieces

2. Slab NOT defined

 The head MUST be positioned exactly when you want the first left to right cut to start. And the center of the blade to

be center over where you want the first back to front cut to start.

a. ADD

b. Piece Width= Width of pieces

c. Piece Length= Length of pieces

d. Piece Angle= affects vertical cuts only

e. Number of parts 1st series= number of columns

f. Number of parts 2

series= number of rows

a. You will have to do the math and figure out how many pieces in each type of row

g. X Position= adjustment left or right

h. Y Position= adjustment up or down

i. Cut Angle= changes the rotation of all the pieces

3. Menu

4. See SEND PROGRAM for further instructions
