BACA SYSTEMS BOSS - Lubrication Schedule and Recommendations; Lubrication Points and Oil Types

BOSS Saw User Manual V1.0
5/9/2019
38
Lubrication periods based on 8-hour workdays.
NO.
Lubrication Position
Capability
Replacement
Frequency
Recommended Oil Type
Comment
1
Ball screw holder
Trimonthly
Mobilux EP series 2
Shell Alvaniz EP grease R2
Add NO.2 high temperature resistant
grease by pulling pneumatic grease gun
3-5 times.
2 total positions.
2
Hydraulic unit
27L
1
Annually
2
Semiannually
Mobil DTE R26
Shell Tellus oil R68
1
Change lubricant/add oil when low.
2
Clean filter.
3
Grease resistant
lubricator
1200CC
Add if low
Mobilux EP series 00
Shell Alvaniz EP grease R00
Automatic lubrication/add when low.
16 total positions
4
F.R.L combination
Daily
Mobilgard 40 series 340
Shell Rimula D40
(a): Check daily for water – if so drain
prior to starting machine.
(b): Add 40% engine oil fully from (d)
position prior to starting machine.
Caution: Adjust air pressure value (c) to
zero before adding oil for (d).
5
Left/right ball screw
holder
Trimonthly
Mobilux EP series 2
Shell Alvaniz EP grease R2
Add NO.2 high temperature resistant
grease by pulling pneumatic grease gun
3-5 times.
1 total positions.
6
Up/down ball screw
holder
Trimonthly
Mobilux EP series 2
Shell Alvaniz EP grease R2
Add NO.2 high temperature resistant
grease by pulling pneumatic grease gun
3-5 times.
1 total positions.
7
Gearbox seat
5L
Add if low
Mobilux HD 150
Shell Spirax HD 150
Add oil when low.
8
Support point for tilt
table cylinder
Monthly
Mobilux EP series 2
Shell Alvaniz EP grease R2
Add NO.2 high temperature resistant
grease by pulling pneumatic grease gun
3-5 times.
2 total positions.
9
Table hinge
Monthly
Mobilux EP series 2
Shell Alvaniz EP grease R2
Add NO.2 high temperature resistant
grease by pulling pneumatic grease gun
3-5 times.
2 total positions.
10
Vacuum pump
0.7L
Semiannually
VG68 Mineral oil
Mobil DTE R68
Shell Tellus oil R68
Check oil color/quantity daily. If color is
clear and below 1/2 full add until 2/3
full. If oil is milky white turbid or dark
particles change immediately.
Change oil semiannually.
11
Vacuum tank
Monthly
Check and drain water monthly.
Caution: turn power off before draining.
ATTENTION: Mechanical failure possible without oil replacement or use of non-recommended oil.
