Setup Fyrite
InTech
Manual
14 0024-9486 Rev 2
2.2. Front Panel Buttons
Button Description
•
Powers the analyzer ON and OFF. Hold this button
down for at least 2 seconds to turn the power OFF.
•
Toggles the backlight ON and OFF while the analyzer is
turned ON.
•
UP (
), DOWN (
), LEFT (
), and RIGHT (
) arrows
are context-specific navigation buttons for the menus.
•
UP (
) and DOWN (
) arrow buttons scroll to menu
options that are hidden from view (when a side scroll
bar is displayed indicating additional information).
•
UP (
) and DOWN (
) arrow buttons cause the
displayed value to increase or decrease accordingly.
•
LEFT (
) and RIGHT (
) arrow buttons jump to the
top and bottom of lists, respectively.
•
LEFT (
) and RIGHT (
) arrow buttons position the
active cursor on specific elements of a value to be
changed.
•
The ENTER button. Performs the action selected.
•
While in the HOLD screen, turns the sample pump on,
displays the RUN screen, and begins a combustion
test.
•
While in the RUN screen, turns the sample pump off,
displays the HOLD screen and the last set of combustion
data.
•
Displays the HOLD screen while pressing it from most
menus.
•
Returns the display to the HOLD screen while pressing it
during the shutdown sequence.
•
The ESC button cancels most operations and displays the
previous screen.
•
Pressing function keys accepts the corresponding function
defined above that key at the bottom of the display (for
example, PRINT, SAVE, MENU, etc.).
