8.5 MISC
In the Miscellaneous submenu the limits and delay settings can be changed
 Inlet Tubing volume: Setting to include the volume of the inlet hose in the
measurement process
 Show custom unit: Selecting a check mark
will show a Custom
calculated value instead of pmol/min.
 Delay after Cycles: Enter a value will stop the measurement process for a
period of time after the entered cycles (time cam be selected by Delay time)
 Delay Time: This is the amount of delay time before a new measurement
cycle will start. Applicable only when the option; ” Delay after Cycles” is
activated
 Detection limit minimum: A detection limit above this value can be seen as
unreliable. An Erroneous Measurement result will occur.
 Detection limit threshold: Internal calculation value (100 %)
 10 ml chamber volumes: Selecting a check mark
will activate settings
for a 10 ml reaction chamber. Deselecting a check mark will activate
settings for a larger reactor.
 Custom unit: For setting a calculated Custom value and unit.
 Bubble sensor sensivity: This is the sensitivity of bubble check for incoming
water and may occur an alarm. (value can be set lower when incoming water
contains air bubbles).
 2nd inlet: When selecting a check mark here,
all pump steps, except
the filtration step ,are done via 2
nd
inlet. (this will also add valve 3.3 in service
menu
 Enclosure Heating: When selecting a check mark here
will turn on the
cabinet heater (Optional)
 Enclosure setpoint: Setpoint for cabinet temperature.
 Post filtration from 2nd inlet When selecting a check mark here
This
inlet will be used for rinsing the reactor with external fresh- or demi water to
optimize a measurement.
 Post filtration volume: Setting volume to use for post filtration
