BAD BOY TRACTOR
CHECKING AND ADJUSTING
FAN BELT
Loosen the generator mounting bolts
and move the generator to adjust the
tension of the fan belt.
If the fan belt still slips after the gen-
erator is moved to the maximum, re-
place the belt with a new one.
New belts must be inspected after 50
hours of running.
(1) Fan belt
CHECKING AND ADJUSTING
TOE-IN
If the toe-in is not properly aligned,
the steering wheel may be uncontrol-
lable or the tractor may produce an
abnormal vibration.
Measure the distance A and the dis-
tance B of the front wheels and see
if the front one is narrower than rear
one by 0.2- 0.3 in. (4 - 8 mm).
If not, loosen the mounting nuts at
the end of the cylinder rod on both
sides and adjust the length of the
screws.
(1) Mounting nut (2) Cylinder rod
Tighten the nuts when the toe-in is
0.2 - 0.3 in. (4 - 8 mm). Be sure of
both lengths of the left and right tie
rod ends are the same.
