BAD BOY TRACTOR
PREHEAT INDICATOR
Lamp will light on/off depending on
temperature of engine coolant when
main key switch is turned on.
Lamp will be turned off when heat-
er coil is heated. Start engine after this
lamp is turned o.
It is difficult to start engine in winter
when starting engine before warm up
lamp is turned o. It also causes early
discharge of battery.
(1) Preheat Indicator
FUEL GAUGE
This indicates the remaining fuel level.
Immediately ll the fuel tank if the nee-
dle reads the red area.
(1) Fuel Gauge
1
1
The length of time the thermo-
stat stays on will depend on
the temperature of the engine
coolant.
* Coolant temp :
32°F ~ 60°F 10 sec
32°F ~ 5°F 20 sec
NOTE
