4
-
12
BAD BOY TRACTOR
PTO INDICATOR
This comes on while the PTO shaft is
rotating.
LEFT/RIGHT TURN SIGNAL
INDICATOR
This indicates the condition when op-
erating one of the turn signal lamps
for the desired turning direction.
HIGH BEAM INDICATOR
It indicates the high beam. Select the
low beam for driving on a road.
(1) PTO Indicator (1) Left Turn Signal Indicator
(2) Right Turn Signal Indicator
(1) High Beam Indicator
1
1
2
2
12
1
1
1
1
1
1
4035ch.indb 124035ch.indb 12 2020-09-18 오후 6:29:162020-09-18 오후 6:29:16
