BAD BOY TRACTOR
MAJOR SPECIFICATIONS
Specication BBT 4035CH
PTO Power
PS (kW)
22 (29.5)
Engine
Model Vertical, water cooled 4-cycle, diesel engine
Type A1700N4-BUTC_4
No. of cylinders 3
Bore x Stroke
in.(mm) 3.46 × 3.70 (88 × 94)
Displacement cc 1,715
Horsepower kW (ps) 26 (35)
Revolution rpm 2,600
Max. torque
lb.-ft (Nm) 76 (103)
Battery V 12
Fuel Diesel fuel
Capacity
Fuel tank
u.s. gal (ℓ
)
7.13 (
27)
Engine crankcase
u.s. gal (ℓ)
4.3 (1.14)
Coolant
u.s. gal (ℓ)
1.32 (
5)
Transmission case
u.s. gal (ℓ)
HST: 9.77 (
37)
Dimensions
Overall length
in.(mm) 134.88 (3,426)
Overall width
in.(mm) 56.3 (1,431)
Overall height
in.(mm) 85.9 (
2,181)
※
Dimensions and weights are based on 7-16 / 11.4-24.
