BAD BOY TRACTOR
GREASING
Apply grease every 50 hours. Check
the relevant parts (9 points) be-
fore starting work everyday and add
grease as necessary.
▶
Greasing points
•
Axle bracket (front & rear)
•
Axle tie rod end (LH/RH)
•
Brake and clutch pedals
•
Lift rod (upper/lower)
After working in wet conditions, make
sure to apply grease to the tractor.
CHECKING AND ADJUSTING
STEERING WHEEL
When the steering wheel is turned to the
left and right lightly, there should be free
play for 0.8 - 2.0 in. (20 - 50 mm). If the
extent of the free play exceeds this range,
the steering wheel may feel heavy or the
tractor may not move straight. If the free
play is not normal, have it fixed at your
nearest authorized dealer.
(1) Nipple (A) Free play of steering wheel
•
Check if the steering wheel vi-
brates severely or has no free
play.
WARNING
