BAD BOY TRACTOR
DIFFERENTIAL LOCK
CAUTION
•
Do not drive the tractor at high
speed or make a turn with the
di󰀨erential lock engaged.
IMPORTANT
•
To prevent the power train
from damage, do not press the
differential lock pedal when
one wheel is spinning fast and
the other wheel is stopped.
2. If the wheel traction resistance on
both wheels are not even, the dif-
ferential lock will continue being
engaged. While both wheel trac-
tion resistance is even, the di󰀨er-
ential lock is automatically disen-
gaged. If the di󰀨erential lock is not
disengaged, depress one and an-
other brake pedal separately.
1. When the speed at one wheel
starts to drop, depress the di󰀨er-
ential lock pedal to activate the dif-
ferential lock.
(1) Di󰀨erential Lock Pedal
(A) Release (B) Engage
3. If the tire is rotating idle repeat-
edly, try to engage the di󰀨erential
lock again.
