BAD BOY TRACTOR
Items Lamp Indication Description
DPF regeneration
time reached
Light on
If the DPF has more than a certain amount of soot, it informs
the driver that it is time to regenerate.
[Buzzer] Buzzer sounds 3 times every minute.
DPF regeneration
starts
If driver press the regeneration button for more than 3
seconds in high idle (2850rpm or more), driver can enter the
regeneration mode.
[Buzzer] Buzzer sounds for 2 seconds at start
DPF regeneration
proceeding
Light on
Controlling the exhaust valve to burn soot on the DPF.
[Buzzer] Buzzer sounds once every 3 minutes
Blinking per 0.5 sec
DPF regeneration
complete
Lamp O󰀨
Regeneration is completed after 30 minutes from the start of
regeneration.
[Buzzer] Buzzer sounds 3 times after 3 minutes of DPF
regeneration.
DPF REGENERATION INDICATION
