Bad Boy 5045 CS - High Beam Lamp; Pto Lamp; Turn Signal Lamp

4 - 12
BAD BOY TRACTOR
TURN SIGNAL LAMP
This lamps the condition when operating
one of the turn signal lamps for the desired
turning direction.
HIGH BEAM LAMP
(1) Left Turn Signal Lamp
(2) Right Turn Signal Lamp
1
1
2
2
12
Indicates the head lamps beam’s position.
It will come on when the high beam lamps
are on High beam. On the contrary, if the
head lamps are in the low beam, this lamp
will not be lit.
(1) High Beam Lamp
1
1
1
1
1
1
PTO LAMP
PTO lamp will light up when PTO ON/OFF
switch is turned on.
(1) PTO Lamp
1
1
1
