Bad Boy 5045 CS - Air Conditioner; Wiper Switch

4 - 35
OPERATION DESCRIPTION
4

Do not use the wiper when the wash-
er uid reservoir is empty, otherwise
you will damage the washer pump.

Do not use the wiper if there is any
danger that the fluid will freeze on
the wind-shield. If you do, your vision
could be obscured. For this reason,
use washer uid.
CAUTION
AIR CONDITIONER
(1) Cooling Function (2) Air Flow Rate
(3) Temperature
►COOLING FUNCTION
When the cooling function is on, the air
compressor is worked, then reheated ac-
cording to the temperature setting.
►AIR FLOW RATE
Adjust the air flow rate. The higher the
rate, the more effective the heating or
cooling will be.
WIPER SWITCH
Wiper blades will operate when upper but-
tons of wiper switch are pressed.
W
asher fluid is sprayed on to windshield
and the wipers are operated when buttons
are pressed once more.
Lower buttons will only spout wash liquid.
Wash liquid tank for cleaning is located on
rear left side of cab exterior.
(1) Wiper Switch
(2) Window Washer Fluid Reservoir Tank
