4 - 28
BAD BOY TRACTOR
POSITION CONTROL LEVER
It is used to keep the implement constantly
at a certain position.
A stopper is used to x the position control
lever in the “UP” position while driving on a
road.
When lowering the implement, set the po-
sition control lever, and the implement will
go down to the set position.
(1) Position Control Lever
SCV LEVER
(1) SCV Lever (I)
(2) SCV Lever (II)
It is used to for the rear implement hydro-
static.
LEVER # I II
DETENT N/A REAR
RANGE SHIFT LEVER
(1) Range Shift Lever
[CABIN] [CABIN] [CABIN]
[ROPS]
[ROPS]
