4 - 29
OPERATION DESCRIPTION
4
The range gear is shifted in four lev els (A-B-
C-D). The combination with the main gear
provides 16 stag es (4 stages: HST only) of
gear shift ing. When shifting the range gear,
Operator must stop the tractor.
Operate the range shift lever only af-
ter the tractor is completely stopped.
Shifting the lever during driving can
damage the gears.
NOTE
PARKING BRAKE LEVER
Pull the lever up while depressing the Brake
pedal fully to engage the parking Brake.
To release the parking Brake, step on the
Brake pedal and push the lever down.
Connect both Brake pedals with the coupler.
(1) Parking Brake Lever
[HST]
[MEC.]
