2.3 Operating conditions
In case of extreme variations in ambient temperature and high humidity levels, installation of a
heating resistor is recommended to minimise condensation in the actuator.
Actuatorcoverswithsuppressionofthermalbridges(dualcovers)arerecommended.
● Connecttheheater(HZG)asshowninthewiringdiagram.
● Put the device into service as soon as it is installed.
The actuators are suitable for installation in industrial plants and in waterworks and power
plants with a low pollutant concentration.
Foruseoutdoorsorinanenvironmentwithahighpollutantconcentration,suchasheavytrafc
areas,industrialareas(chemicalplants,sewageplants,etc.),coastalareasandtheopensea,
the actuators must have external parts made of non-corrosive material and must be provided
with a special coating.
When used outdoors, the actuator must be protected with an additional cover against
● rain
● direct sunlight
● strong draughts
● dust
3. TRANSPORT AND STORAGE
Risk of injury caused by failure to observe safety regulations!
Caution
● Wear the required personal and other protective equipment.
● Protecttherotaryactuatorfromimpact,shock,vibrationandsimilarinuences.
● Storetherotaryactuator(orthecompleteactuator/valveassembly)inadryplace.
● Observethetransportandstoragetemperaturelimitsof-20to+60°C.
Table 2. Options for Actuators
2EZ-Fg
Two additional limit switches for signalling end positions or intermediate positions, freely adjustable,
max. 250 V AC, rating for resistive load max. 10 A, for inductive load max. 5 A
Fg5k
5kΩpotentiometer,linearityerror≤0.5%,max.1.5W,contactcurrent30mA
7020A
Digital positioner for actuator control, self adapting
1inputsignal:0(2)…10V,0(4)…20mAor(3-point)
2outputsignals:0(2)…10Vand0(4)…20mA
1 digital input, 2 relays for feedback on end or intermediate positions,
InterfaceRS485ModbusRTU,incl.5kΩpotentiometer
Hzg
Heatingresistorwiththermoswitchagainstmoisturewithautomatictemperatureregulation,
max. 15 Watts
baelz 375 - E42 - 150Nm - 60s - 230V
motorized rotary actuator actuator type torque positioningtimefor90° supply
3.1 Type name
3.2 Accessories and options
