USER MANUAL – M625/M325 DRIVE SYSTEM
13
INSTALLATION
3. Install the throttle, the right e-brake lever,
and the grip on the handlebar.
4. Now with M3 and M5 screws tighten the
throttle and the e-brake lever into position.
5. Connect the e-brake levers and the throttle
to the EB-BUS cable.
6.7 Headlight and Taillight
Installation
1. Tighten the headlight and taillight into
position.
2. Then connect the headlight and taillight to
the EB-BUS cable.
To Next Page
