USER MANUAL – M625/M325 DRIVE SYSTEM
1
SYMBOL INSTRUCTION
If you see the following symbols there is always a
possibility of danger.
The warning symbols are as follows:
Note: This symbol indicates information about
how to use the product and highlights specific
parts of the User's Guide that are important.
Caution: This symbol warns against misuse of
the products that can lead to it being damaged
or polluting the environment.
Danger: This symbol indicates possible health
and safety hazards that may arise, if certain
measures are not taken into consideration.
User Manual: Please read the manual before
using the pedelec. If you are not sure about any
of the topics in the manual, please contact your
retailer for assistance.
1 Guide 2
1.1 Quick Start 2
1.2 Before Each Ride 2
2 Important Notice 3
2.1 For Your Safety 3
2.2 Installation and Maintenance 3
2.3 Laws and Regulations 4
3 Vehicle Transport 4
4 Environmental Tips and Handling Requirements 5
5 Guaranty 5
6 Installation 6
6.1 Summary of the Components 6
6.2 Drive Unit Installation 7
6.3 Display Installation 10
6.4 Battery Installation 11
6.5 Speed Sensor Installation 12
6.6 E-Brake Lever and Throttle Installation 12
6.7 Headlight and Taillight Installation 13
7 Drive Unit 14
7.1 Introduction 14
7.2 Specifications 14
7.3 Maintenance 16
8 Display 17
8.1 Important Notice 17
8.2 Introduction of Display 17
8.3 Product Description 17
8.4 Display Information 18
8.5 Key Definition 18
8.6 Normal Operation 19
8.6.1 Switching the System ON/OFF 19
8.6.2 Selection of Support Levels 19
8.6.3 Selection Mode 19
8.6.4 Headlights / backlighting 19
8.6.5 Walk Assistance 20
8.6.6 SERVICE 20
8.7 Settings 21
8.7.1 “Display Setting” 21
8.7.2 “Information” 25
8.8 Error Code Definition 27
9 Battery 30
9.1 Introductions 30
9.2 Operation 32
9.3 Specifications 36
