USER MANUAL – M625/M325 DRIVE SYSTEM
36
9.3 Specifications
9.3.1 Battery
Primary Settings BT F22.960.C
Rated voltage 50.4 DCV
Nominal Capacity 19.6 Ah
Rate Capacity 19 Ah (@1C/25°C Discharge)
Power 960 Wh
Charging time 6.5h with 4A Charger
Storage (At 35% SOC &-10° ~ 35 °C) 6 months
Riding Distance * Minimum 80km( 1000W motor)
Dimensions (L * W * H) 375*100*149mm
Weight 5.5 ± 0.5 KG
Charger Special 5P charger
* Ideal conditions: Flat terrain, approx. 15km/h average speed, no headwind, approx. 20 °C ambient temperature, high-quality bike compo-
nents, tire tread and pressure with minimal rolling resistance, experienced eBike rider(always shifts gears correctly), additional weight(exclud-
ing bike weight)<70kg.
9.3.2 Charger
• Operating voltage: 100 ACV–240 ACV,
50 – 60 Hz
• Rated output voltage: 58.8 V
• Output current: 4 A ± 0.2 A
• Minimum battery charge voltage: 37.8 ± 2 V
• Timing Protection: 15 ± 1 h
• Temperature protection: NTC < 0 ± 3 °C
or NTC > 65 ± 3 °C
• AC Connector: Meet local standard
• Certificate: FCC, UL62368, RoHs
