USER MANUAL – M625/M325 DRIVE SYSTEM
17
DISPLAY
8 DISPLAY
8.1 Important Notice
• If the error information from the display
cannot be corrected according to the inst-
ructions, please contact your retailer.
• The product is designed to be waterproof. It
is highly recommended to avoid submerging
the display under water.
• Do not clean the display with a steam jet,
high-pressure cleaner or water hose.
• Please use this product with care.
• Do not use thinners or other solvents to
clean the display. Such substances can
damage the surfaces.
• Warranty is not included due to wear and
normal use and aging.
8.2 Introduction of Display
• Model: DP C181.CAN BUS
• The housing material is PC and high strength
material:
• The label marking is as follows:
Note: Please keep the QR code label attached
to the display cable. The information from the
Label is used for a later possible software
update.
8.3 Product Description
8.3.1 Specifications
• Operating temperature: -20℃~45℃
• Storage temperature: -20℃~50℃
• Waterproof: IPX5
• Bearing humidity: 30%-70% RH
8.3.2 Functions Overview
• Speed display (including top speed and
average speed, switching between km and
miles).
• Battery capacity indicator.
• Automatic sensors explanation of the light-
ing system.
• Brightness setting for backlight.
• Indication of assistance support.
• Motor output power and output current
indicator.
• Mileage show (including single-trip distance,
total distance and remaining distance).
