INTRODUCTION
DOCUMENT CONVENTIONS
1 - 4 WBPEEUI240755B0
®
3. Refer to the troubleshooting section to resolve problems if
they occur.
4. Refer to the maintenance section for scheduled mainte-
nance requirements.
5. Refer to the repair and replacement procedures to replace
a module.
6. Use the support services section for information on order-
ing spare modules and warranty information.
DOCUMENT CONVENTIONS
The
in a nomenclature item indicates variables for that posi-
tion, e.g., IMCIS
2.
GLOSSARY OF TERMS AND ABBREVIATIONS
Table 1-1 contains those terms and abbreviations that are
unique to Elsag Bailey or have a definition that is different
from standard industry usage.
Table 1-1. Glossary of Terms and Abbreviations
Term Definition
EWS Engineering work station.
Function Code (FC) An algorithm which manipulates specific functions.
These functions are linked together to form the con-
trol strategy.
I/O Expander Bus Parallel communication bus between the control and
I/O modules.
MFP Multi-function processor module. A multiple loop con-
troller with data acquisition and information process-
ing capabilities.
MMU Module mounting unit. A card cage that provides
electrical and communication support for INFI 90
OPEN/Network 90 modules.
OIS Operator interface station. Integrated operator con-
sole with data acquisition and reporting capabilities.
It provides a digital access into the process for flexi-
ble control and monitoring.
TM Termination module. Provides input/output direct
connection between plant equipment and the INFI 90
OPEN/Network 90 modules.
TU Termination unit. Provides input/output direct con-
nection between plant equipment and the INFI 90
OPEN/Network 90 modules.
