INSTALLATION
FUSING
3 - 8 WBPEEUI240755B0
®
FUSING
The CIS and QRS modules do not have any on board fusing
requirements.
PREOPERATING ADJUSTMENTS
The CIS and QRS modules do not require any adjustments
prior to operation.
Figure 3-3. Cable Connections and Termination
T00087B
P1
P1
P3 P1
P3 P1
P2
P2
NKTM01
OR
NKTU02
NICS01
IMCIS12/
IMQRS12
IMCIS12/
IMQRS12
NTCS04
NKTU01
4 ANALOG INPUTS
(1-5 VDC, 4-20 mA)
3 DIGITAL INPUTS
(24/48/125 VDC, 120 VAC)
4 ANALOG INPUTS
(1-5 VDC, 4-20 mA)
3 DIGITAL INPUTS
(24/48/125 VDC, 120 VAC)
2 ANALOG OUTPUTS
(1-5 VDC, 4-20 mA)
4 DIGITAL OUTPUTS
(24 VDC AT 250 mA)
2 ANALOG OUTPUTS
(1-5 VDC, 4-20 mA)
4 DIGITAL OUTPUTS
(24 VDC AT 250 mA)
