Analog Output Default Jumpers (J7, J8, J12, J14, J10, J16)
The analog output default jumpers determine the I/O module
analog output default values. These are the values or levels for
the analog outputs during system start-up (power up) or bus
fault error (time-out).
Select either a zero percent or 100 percent power up output.
Selecting zero percent will output four milliamps or one VDC;
selecting 100 percent will output 20 milliamps or five VDC.
If the bus fault timer expires (times out), the digital outputs
de-energize and the analog outputs change to the default value
selected. A time-out occurs when the I/O module does not
receive a clock signal from the MFP. The time-out options are
to hold or go to power up state. The outputs will stay at their
current values during a time-out if the hold option is selected;
they will change to the power up values (zero or 100 percent) if
the go to power up state is selected.
Refer to Figure 3-1 for location of the jumpers and Table 3-2 for
jumper settings.
NOTE:
Jumpers J10 and J16 are not required.
28 0 11100 46 1 01110
29 0 11101 47 1 01111
30 0 11110 48 1 10000
31 0 11111 49 1 10001
32 1 00000 50 1 10010
33 1 00001 51 1 10011
34 1 00010 52 1 10100
35 1 00011 53 1 10101
36 1 00100 54 1 10110
37 1 00101 55 1 10111
38 1 00110 56 1 11000
39 1 00111 57 1 11001
40 1 01000 58 1 11010
41 1 01001 59 1 11011
42 1 01010 60 1 11100
43 1 01011 61 1 11101
44 1 01100 62 1 11110
45 1 01101 63 1 11111
1 = OPEN; 0 = CLOSED
Table 3-1. S1 Address Switch Settings
(continued)
ADDR
MSB LSB
ADDR
MSB LSB
3 45678 3 45678
