Bailey IMCIS12 - Appendix C - Quick Reference; Introduction

QUICK REFERENCE
INTRODUCTION
C - 2 WBPEEUI240755B0
®
Table C-1. S1 Address Switch Settings
ADDR
MSB LSB
ADDR
MSB LSB
345678 345678
0 000000 32 100000
1 000001 33 100001
2 000010 34 100010
3 000011 35 100011
4 000100 36 100100
5 000101 37 100101
6 000110 38 100110
7 000111 39 100111
8 001000 40 101000
9 001001 41 101001
10 001010 42 101010
11 001011 43 101011
12 001100 44 101100
13 001101 45 101101
14 001110 46 101110
15 001111 47 101111
16 010000 48 110000
17 010001 49 110001
18 010010 50 110010
19 010011 51 110011
20 010100 52 110100
21 010101 53 110101
22 010110 54 110110
23 010111 55 110111
24 011000 56 111000
25 011001 57 111001
26 011010 58 111010
27 011011 59 111011
28 011100 60 111100
29 011101 61 111101
30 011110 62 111110
31 011111 63 111111
1 = OPEN; 0 = CLOSED
Table C-2. Analog Output Default Jumpers
Analog
Output
Time-Out Option Power-Up State
Jumper
Go To
Power-Up
Hold Jumper 0% 100%
1 J82-31-2J72-31-2
2 J14 2-3 1-2 J12 2-3 1-2
