SPECIFICATIONS
1 - 6 WBPEEUI240755B0
®
SPECIFICATIONS
Table 1-5 contains specifications relative to the IMCIS12 and
IMQRS12 modules.
NTCS04 Termination unit, control I/O
NKTM01 Cable, termination module
NKTU01/11 Cable, termination unit
NKTU02/12 Cable, termination module
Table 1-4. Related Hardware
(continued)
Nomenclature Description
Table 1-5. Specifications
Property Characteristic/Value
Power Requirements
Voltage 5 VDC (
±
5%)
+15 VDC (-2.5%, +5%)
-15 VDC (-5%, +2.5%)
+24 VDC (
±
10%) (supplied via P3 connector from termination unit)
Current
Dissipation (logic only)
Overvoltage category for I/O II, per IEC 1010-1
Current Typical Maximum
+5 V 265 mA 332 mA
+15 V 27 mA 35 mA
-15 V 23 mA 30 mA
+24 V 46 mA 50 mA
Current Typical Maximum
+5 V 1.33 W 1.66 W
+15 V 405 mW 525 mW
-15 V 345 mW 450 mW
+24 V 1.10 W 1.2 W
