TERMINATION MODULE (NICS01) CONFIGURATION
INTRODUCTION
B - 2 WBPEEUI240755B0
®
Analog Output
Application/Signal Type Dipswitch Configuration S5
Both outputs in voltage mode
Output 1 in voltage mode, output 2 in
current mode
Output 1 in current mode, output 2 in
voltage mode
Both outputs in current mode
Table B-1. NICS01 Dipswitch Configuration
(continued)
1 2 3 4
OPEN
1 2 3 4
OPEN
1 2 3 4
OPEN
1 2 3 4
OPEN
TP27119A
Figure B-1. NICS01 Terminal Assignments
COMMON +24 VDC
1
11 1 1234
2
22 23
3
3
4
4
5 6 7 8 9 10 11121314 151617181920 21 232425262728293022
ANALOG INPUT ANALOG
OUTPUT
DIGITAL INPUT SERIAL
LINK
DIGITAL OUTPUT
TP27165A
TERMINAL NUMBER
