Appendix (continued)
No. 911448-726 EN ∙ 02.130901 ∙ B21; Subject to modification. Replaces F14.
11.2 Menu structure: analog mode
Main menu
(1st level)
Submenu
(2nd level)
Parameter Button(s) Function Section
1
Ano
Analog sensor value (in digits) 7.2
2
t A
Teaching in switchpoints 7.3.2
SAL o
Teach in switchpoint1
SAHi
Teach in switchpoint2
3
[ ] c onf
Submenu: Configuration 7.6
a
SoA
Adjusting the operating mode (switching – analog) 7.6.1
S
Switching (this overview applies)
A
Analog output (see section 11.1 Switching operating
mode menu structure)
b
out
Adjusting the switching power amplifier type/analog
output
7.6.2
P no
PNP N.O.
n no
NPN N.O.
4
[ ] di SP
Submenu: Display settings 7.7
g
F W
Display of software version 7.7.1
h
HW
Display of hardware version 7.7.1
i
L uM
Adjusting the luminosity 7.7.2
50
Luminosity approx 50%
100
Luminosity 100%
j
180
Display text rotation (0/180°) 7.7.3
0
Display not rotated.
180
Display rotated 180°.
k
VaL
Dampening rate display in RUN mode 7.7.4
Off
No display of dampening in digits in RUN mode
On
Display of dampening in digits in RUN mode
7
E nd
Closing the menu 7.8
BAE SA-CS-026-YP-BP02 / BAE SA-CS-026-YP-BP00,3-GS04
Comfort Sensor Amplifier
