6．EtherNet/IP Settings
■Input area (Network Module to Controller)
Name Data type Network publish
Data size (byte)
EIP002_Standard_IO_ports_IN BYTE[8] Input 8
EIP002_IOLink_port0_1_IN BYTE[96] Input 96
EIP002_IOLink_port2_3_IN BYTE[96] Input 96
EIP002_IOLink_port4_5_IN BYTE[96] Input 96
EIP002_IOLink_port6_7_IN BYTE[96] Input 96
*Relationship between the global variables and the Network Module data
Global variable
Network Module
Data
allocation
Bit
7 6 5 4 3 2 1 0
EIP002_Standard_IO_ports_IN[0]
Standard
I/O ports
I32 I34 I22 I24 I12 I14 I02
I04
EIP002_Standard_IO_ports_IN[1]
I72 I74 I62 I64 I52 I54 I42
I44
EIP002_Standard_IO_ports_IN[2]
S3 S2 S1 S0
EIP002_Standard_IO_ports_IN[3]
S7 S6 S5 S4
EIP002_Standard_IO_ports_IN[4]
O32 O34 O22 O24 O12 O14 O02 O04
EIP002_Standard_IO_ports_IN[5]
O72 O74 O62 O64 O52 O54 O42 O44
EIP002_Standard_IO_ports_IN[6]
0 0 0 0 0 NA PS PA
EIP002_Standard_IO_ports_IN[7]
0 0 0 0 0 0 0 0
EIP002_IOLink_port0_1_IN[0]
IO-Link
port 0
IO-Link port 0 input process data
Stores the process data "Byte0 (PD0)" of the
Proximity Sensor.
EIP002_IOLink_port0_1_IN[1]
IO-Link port 0 input process data
Stores the process data "Byte1 (PD1)" of the
Proximity Sensor.
EIP002_IOLink_port0_1_IN[2] to [31]
IO-Link port 0 input data
EIP002_IOLink_port0_1_IN[32]
0 0 0 0 0 0 DC IOL
EIP002_IOLink_port0_1_IN[33]
SC 0 0 0 0 PDI DF VF
EIP002_IOLink_port0_1_IN[34] to [35]
Vendor ID
EIP002_IOLink_port0_1_IN[36] to [38]
Device ID
EIP002_IOLink_port0_1_IN[39] to [41]
Event 1
EIP002_IOLink_port0_1_IN[42] to [44]
Event 2
EIP002_IOLink_port0_1_IN[45] to [47]
Event 3
EIP002_IOLink_port0_1_IN[48] to [79]
IO-Link
port 1
IO-Link port 1 input data
EIP002_IOLink_port0_1_IN[80]
0 0 0 0 0 0 DC IOL
EIP002_IOLink_port0_1_IN[81]
SC 0 0 0 0 PDI DF VF
EIP002_IOLink_port0_1_IN[82] to [83]
Vendor ID
EIP002_IOLink_port0_1_IN[84] to [86]
Device ID
EIP002_IOLink_port0_1_IN[87] to [89]
Event 1
EIP002_IOLink_port0_1_IN[90] to [92]
Event 2
EIP002_IOLink_port0_1_IN[93] to [95]
Event 3
