6．EtherNet/IP Settings
9
6. EtherNet/IP Settings
This section describes the parameters, global variables and tag sets that are all defined in this
guide.
Hereinafter, the Network Module is referred to as the "Destination Device" in some
descriptions.
6.1. Parameters
The parameters set in this guide are shown below.
6.1.1. EtherNet/IP Communications Settings
The parameters required to connect the Controller and the Network Module via EtherNet/IP
are shown below.
Item Controller (Node 1) Network Module (Node 2)
IP address 192.168.250.1 192.168.250.2
Subnet mask 255.255.255.0 255.255.255.0
6.1.2. Destination Device Settings
The parameter of the Network Module is shown below.
Item Set value Remarks
0015 Port function 1 Port 0: IO-Link mode
Ports 1-7: Standard I/O mode
The following figure shows the data configuration of 0015 Port function and the relationship
between each port and set value of 0015 Port function. The IO-Link mode is set when the set
value for port is 01, whereas the standard I/O mode is set when the set value for port is 00.
With Network Configurator, the set value of 0015 Port function is "1" in decimal that
represents a binary value of "00 00 00 00 00 00 00 01".
0015 Port function
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Set value 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1
For example, if setting Ports 0-2 to IO-Link mode and Ports 3-7 to standard I/O mode, the set
value of 0015 Port function will be "21" in decimal that represents a binary value of "00 00 00
00 00 01 01 01".
Port 7
set value
Port 6
set value
Port 5
set value
Port 4
set value
Port 3
set value
Port 2
set value
Port 1
set value
Port 0
set value
