Balluff BNI EIP-50 105-Z015 Series User Manual

6．EtherNet/IP Settings
15
6.3. Tag Sets
The tag sets to perform tag data links are shown below.
The data in the tag sets are assigned in ascending order of the following OUT No. and IN No.
■Output area (Controller to Network Module)
Tag set name (Originator variable) Data size (byte)
EIP002_OUT 262
OUT No. Tag name (Global variable) Data size (byte)
1 EIP002_Standard_IO_ports_OUT 6
2
EIP002_IOLink_port0_1_OUT
64
3 EIP002_IOLink_port2_3_OUT 64
4 EIP002_IOLink_port4_5_OUT 64
5 EIP002_IOLink_port6_7_OUT 64
■Input area (Network Module to Controller)
Tag set name (Originator variable) Data size (byte)
EIP002_IN 392
IN No. Tag name (Global variable) Data size (byte)
1 EIP002_Standard_IO_ports_IN 8
2 EIP002_IOLink_port0_1_IN 96
3 EIP002_IOLink_port2_3_IN 96
4 EIP002_IOLink_port4_5_IN 96
5 EIP002_IOLink_port6_7_IN 96
