7．EtherNet/IP Connection Procedure
50
7.4.5. Transferring the Tag Data Link Parameters
Transfer the tag data link parameters to the Controller.
1
Right-click the device icon of
Controller (Node 1) in the
Network Configuration Pane
and select Parameter -
Download from the menu.
2
The dialog box on the right is
displayed. Confirm that there is
no problem, and click Yes.
3
The tag data link parameters
are downloaded from Network
Configurator to Controller.
4
The dialog box on the right is
displayed. Check the contents
and click OK.
