AOI_BNI006A_50_31_040 User Guide Page 3 of 26
1.0 Scope
1.1 This User Guide describes the installation, use and maintenance of the Add On Instruction (AOI)
software module for the BNI EIP-502-105-Z015. This software module is designed for use with
RSLogix5000.
2.0 Products
2.1 This guide was developed for use with the software module AOI_BNI004A_40_27_041.L5X. This
software module is available for download at the web site www.Balluff.com/AOI.
2.2 This software module was developed for use with the Balluff EtherNet/IP Connectivity block BNI EIP-
508-105-Z015 (hardware version 5.0, firmware version 3.1).
2.3 For the development of this software module and hardware configuration, the following system
components were used and validated:
2.3.1 RSLogix5000, version 18.01 (or later)
2.3.2 Rockwell 1756-L63 controller

Balluff BNI006A Specifications

General

Brand	Balluff
Model	BNI006A
Category	Control Unit
Language	English
