1.19 Appendix A. Specific Camera / Sensor Data 257
1.19.2.1.6.3 Timings For calculating the frame rates, please use the frame rate calculator of the online manual:
See also
https://www.matrix-vision.com/manuals/mvBlueNAOS/mvBlue_models_BVS←-
_CA-BN2-0246AC_.html#mvBC_subsubsection_sensors_CMOS_models_BVS_CA-←-
BN2-0246AC_Calc
The following trigger modes are available:
Setting (GenICam) Mode / Setting (obsolete "Device
Specific")
Description
"TriggerSelector =
FrameStart"
"TriggerMode = Off"
Continuous Free running, no external trigger
signal needed.
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
Software"
"ExposureMode = Timed"
To trigger one frame execute
the TriggerSoftware@i command
then.
OnDemand Image acquisition triggered by
command (software trigger).
"TriggerSelector =
AcquisitionActive"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
LevelLow"
"ExposureMode = Timed"
OnLowLevel Start an exposure of a frame as
long as the trigger input is below
the trigger threshold. (No Frame←-
Trigger!)
"TriggerSelector =
AcquisitionActive"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
LevelHigh"
"ExposureMode = Timed"
OnHighLevel Start an exposure of a frame as
long as the trigger input is above
the trigger threshold. (No Frame←-
Trigger!)
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
FallingEdge"
"ExposureMode = Timed"
OnFallingEdge Each falling edge of trigger signal
acquires one image.
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
RisingEdge"
"ExposureMode = Timed"
OnRisingEdge Each rising edge of trigger signal
acquires one image.
