1.13 GenICam and advanced features 79
1.13.9 Chunk Data Control
The "Chunk Data Control" contains features like
Feature name (acc. to SFNC
(p. 121))
Property name (acc. to mvIMPACT
Acquire (p. 119))
Description
ChunkModeActive chunkModeActive Activates the inclusion of chunk
data in the payload of the image.
ChunkSelector chunkSelector Selects which chunk to enable or
control.
ChunkEnable[ChunkSelector] chunkEnable Enables the inclusion of the se-
lected chunk data in the payload of
the image.
ChunkImage chunkImage Returns the entire image data in-
cluded in the payload.
ChunkOffsetX ChunkOffsetX Returns the offset x of the image
included in the payload.
ChunkOffsetY chunkOffsetY Returns the offset y of the image
included in the payload.
ChunkWidth chunkWidth Returns the width of the image in-
cluded in the payload.
ChunkHeight chunkHeight Returns the height of the image in-
cluded in the payload.
ChunkPixelFormat chunkPixelFormat Returns the pixel format of the im-
age included in the payload.
ChunkTimestamp chunkTimestamp Returns the timestamp of the im-
age included in the payload at
the time of the FrameStart internal
event.
etc.
related to the Chunk Data Control.
A description can be found in the image acquisition section of the "mvIMPACT Acquire API" manuals.
