38
1.9.2 mvBlueNAOS4
1.9.2.1 Dimensions
1.9.2.1.1 BVS CA-BN4-xxxxx-x5x510 (Board-level)
Figure 3: Connectors BVS CA-BN4-xxxxx-x5x510
mvBlueNAOS4
Size of body (w x h x l) 55 x 40 x 26.5 mm
MATRIX VISION GmbH
