1.13 GenICam and advanced features 83
1.13.14 mv Logic Gate Control
The "mv Logic Gate Control" contains features like
Feature name (acc. to SFNC
(p. 121))
Property name (acc. to mvIMPACT
Acquire (p. 119))
Description
mvLogicGateANDSelector Selects the AND gate to configure.
mvLogicGateANDSource1 Selects the first input signal of the
AND gate selected by mvLogic←-
GateANDSelector.
mvLogicGateANDSource2 Selects the second input signal of
the AND gate selected by mv←-
LogicGateANDSelector.
mvLogicGateORSelector Selects the OR gate to configure.
mvLogicGateORSource1 Selects the first input signal of the
OR gate selected by mvLogic←-
GateORSelector.
mvLogicGateORSource2 Selects the second input signal of
the OR gate selected by mvLogic←-
GateORSelector.
mvLogicGateORSource3 Selects the third input signal of the
OR gate selected by mvLogic←-
GateORSelector.
mvLogicGateORSource4 Selects the fourth input signal of
the OR gate selected by mvLogic←-
GateORSelector.
related to control the devices Logic Gate Control parameters. It performs a logical operation on one or more logic
inputs and produces a single logic output.
The use case Creating different exposure times for consecutive images (p. 166) shows how you can create
different exposure times with timers, counters and the logic gate functionality.
See also
Triggering of an indefinite sequence with precise starting time (p. 173)
