1.13 GenICam and advanced features
1.13.1 Introduction
In wxPropView (p. 65), you can see them in "Setting -> Base -> Camera -> GenICam":
Figure 1: wxPropView - GenICam controls (depends on device and FW version)
As you can see, there are some controls with and without the prefix "mv".
• "mv" prefix features are unique non-standard features developed by MATRIX VISION.
• Without "mv" are standard features as known from the Standard Feature Naming Convention of GenICam
properties (p. 121) (SFNC).
All those features are "camera based / device based" features which can also be accessed using the camera with
other GenICam (p. 113) compliant third-party software.
Note
Do not mix up the camera based / device based features with the features available in "Setting -> Base
-> Image Processing". Theses features are driver based features which are processed by the software
and therefore need CPU load.
1.13.2 Device Control
The "Device Control" contains the features like
