50
Characteristics of input voltage
Characteristics min. nom. max. Unit
Camera power supply 5 12 17 V
Camera current supply 1 1.8 A
Characteristics of the digital inputs
Figure 10: DigIn
Opto DigIn
Characteristics min. nom. max. Unit
U
Opto DigIn_LOW
/ V
IL
(low level input voltage) 0 1 V
U
Opto DigIn_HIGH
/ V
IH
(high level input voltage) 2.5 28 V
I
max
8 mA
Switching Frequency 5 MHz
Characteristics of the digital outputs
Figure 11: DigOut
