52
Features mvBlueNAOS2 mvBlueNAOS4
Image Memory -
Flash (FPGA Configuration, Device Specific Data) 16 MByte
PCIe Interface x4 Gen2
PCIe Bandwidth max. 16 Gbit/s
Max. effective PCIe Bandwidth 12.8 Gbit/s
Bandwidth FPGA Pipeline 800 MPixel/s 1300 MPixel/s
SLVS Lanes 16 -
SLVS-EC Lanes - 4
Inputs 4
Outputs 4
RS232 Controlling e.g. varioptic liquid lens, lights, etc.
Environment
Ambient Temperature
Operation 0..45 deg C / 30 to 80% RH
Storage -20..60 deg C / 20 to 90% RH
Protection class
1
IP30
Weight without lens approx. 71 g approx. 81.6 g
Power supply (PWR_IN)
P
typ
4 W 6 W
1
not evaluated by UL
MATRIX VISION GmbH
