Micropulse Linear Position Transducer
Absolute Quadrature Output
Rod Style & Profile Style Housings
Accessories (Order Separately) – Rod Style Housing





Jam Nut
BTL5-JAM-NUT
Slotted Magnet
BTL5-P-1013-4S
Small Diameter Magnet
BTL5-P-1012-4R
Ring Magnet
BTL5-P-1013-4R
