Balluff MICROPULSE Series User Manual

1-800-543-8390 • WWW.BALLUFF.COM
6
Micropulse Linear Position Transducer
Absolute Quadrature Output
Rod Style & Profile Style Housings
Mechanical Dimensions/Installation – Profile Style Housing
Accessories (Order Separately) – Profile Style Housing





PL0001
14
D
9
1
50 +4
68
50
C
38
20
28
Ø4.2
Control Arm
BTL-Z-5-GS08-_ _ _ _*-A
* Specify length in mm
Extended Range
Floating Magnet
BTL5-P-5500-2
Floating Magnet
BTL5-P-3800-2
Lateral offset:
C = ± 15mm
Vertical distance
of magnet:
D = 5...15mm
Lateral offset:
C = ± 2mm
Vertical distance
of magnet:
D = 0.1...4mm






Swivel Eye
BTL5-SWIVEL-EYE
Mounting Foot
BTL-P-M5-VZ








Mounting Feet
BTL5 P-M5-VZ
(Order separately)
Captive Sliding Magnet
BTL5-F-2814-1S
(Order separately)
M5x22 Socket Head Screws
(Supplied with mouting feet)
Floating Magnet
BTL5 P-3800-2
(Order separately)

Balluff MICROPULSE Series Specifications

General

Measurement Principle	Magnetostrictive
Output	Analog, Digital (SSI, Profibus)
Operating Voltage	10 VDC to 30 VDC
Protection Class	IP67
Temperature Range	-40°C to +85°C
Housing Material	Stainless steel or aluminum
Linearity	±0.02% F.S. (depending on model)
Electrical Connection	M12 connector
Resolution	Up to 1 μm (depending on model)
