4.2 General use
Before starting use, the important instructions in Chapter 4.1 should always be heeded!
Countdown operation
Action Display Remark
1
Turning on the generator
Turn "POWER" control dial all
the way to the left.
Activate the mains switch
- The display is lit after
3 seconds.
MIN/SEC: last set value
CYCLE: last set value
("-" = Max.)
POWER: 000 %
The green control light is lit
When the generator is turned on, the
most recently used operating mode
becomes active.
It is possible to switch to continuous
operation using the RESET key.
After the start-up process, the
generator will not react to further
key presses!
Numeral 5
2
Entering settings
Through progressive pressing
of the MODE key, allow the
"MIN", "SEC", and "CYCLE"
displays to fl ash successively.
Set the time and/or the
pulsation level with the +/-
keys. If the keys are pressed
and held for more than 2
seconds, a fast scroll will
occur!
MIN/SEC: last set value
CYCLE: last set value
("-" = Max.)
POWER: 000 %
Start is possible without entering
a new program - currently saved
settings.
No input within 10 sec. (display
fl ashing)
- exit from input mode,
no saving. The display resets
to the last current
value.
Numeral 5
3
Ending a programming step
(saving)
Confi rm settings with the
MODE key until the display
stops fl ashing.
MIN/SEC: newly set value
CYCLE: newly set value
POWER: 000 %
The program entered is saved.
During operation, the POWER should
be set and is modifi able.
Numeral 5
4
Programming without
permanent saving
Do not confi rm settings with
the MODE key.
MIN/SEC: newly set value
CYCLE: newly set value
POWER: 000 %
Start is possible without entering a
new program
- currently saved settings,
by pressing Start within 10 seconds.
Press the RESET key for a new
entry.
Numeral 5
5
Start
Press the START/STOP key
on the generator or transducer,
or activate the foot switch.
MIN/SEC: runs in reverse
CYCLE: newly set value
POWER: for the moment in
%
If the power display expires,
the ultrasonic transducer is
not connected. To connect the
transducer, no program should be
started. Finally, restart.
6
Interrupting
Activate the START/STOP
key on the generator, the
transducer, or the foot switch.
MIN/SEC: remaining time
CYCLE: newly set value
POWER: 000 %
During the interruption, the colon
fl ashes between MIN/SEC.
The user has the option of entering
new settings or to
proceed with operation.
- Currently saved setting
7
Continuation
Press the START/STOP key
on the generator or transducer,
or activate the foot switch.
MIN/SEC: Time runs in
reverse
CYCLE: newly set value
POWER: for the moment in
%
At the end of the time program,
00 min, 00 sec is displayed. The
pulsation level is retained. After a
short time, the display switches to the
previously set program.
Start
Start
Start
Start
18 / 44 51436a GB/2017-10
