1.3 CE conformity
SONOPULS ultrasonic homogenisers are declared as IVD products and satisfy the CE marking
criteria for the European Directives:
- IVD directive
- Low-voltage directive
- Electromagnetic compatibility directive
in their currently valid versions.
A declaration of conformity can be requested from the manufacturer by providing the serial
number.
1.4 Technical data
SONOPULS ultrasonic homogenisers are interference-free and marked with a (-.
Safety: EN 61010-1,
EMC: EN 61326-1
/
1.4.1 HF Generator (GM)
Generator GM 2070 GM 2200 GM 2070-U GM 2200-U
HF power
/2
70 W 200 W 70 W 200 W
HF frequency 20 kHz 20 kHz 20 kHz 20 kHz
Mains connection 230 V~ (± 10 %) 50/60 Hz 115 V~ or 230 V~ (± 10 %) 50/60 Hz
Weight 2.5 kg 5.5 kg
Dimensions
(l × w × h)
257 × 180 × 115 mm 255 × 272 × 115 mm
8 / 44 51436a GB/2017-10
