Q5X with Dual Discrete Outputs and IO-Link Quick Start Guide
Continued from page 5
4PinFemaleand5PinMaleThreadedM12Cordset—DoubleEnded
Model Length"L1" Style Pinout
M12 X 1.0
43.5 ± 0.5
“L1”
ø 5.9
M12 X 1.0
ø 14.5
ø 14.5
40 ± 0.5

Female
2
3
4
1

1=Brown
2=White
3=Blue
4=Black
Use these cordsets to connect the RSD1 to any PLC or IO block.
5PinMaleThreadedand5PinFemaleQuickDisconnectM12CordsetwithShield—DoubleEnded
Model Length"L1" Style Pinout(Male) Pinout(Female)
MQDEC3-503SS 0.91m(2.99ft)
FemaleStraight/MaleStraight

1
4
5
3
2

2
3
4
1
5

MQDEC3-506SS 1.83m(6ft)
MQDEC3-515SS 4.58m(15ft)
MQDEC3-530SS 9.2m(30.2ft)
M12 x 1
14.5
ø 5.9
14.5
“L1”
47.4
47.4
M12 x 1

1=Brown
2=White
3=Blue
4=Black
5=Gray
5PinThreadedM12CordsetswithShield—SingleEnded
Model Length Style Dimensions Pinout(Female)
MQDEC2-506 2m(6.56ft)
Straight
44 Typ.
ø 14.5
M12 x 1

2
3
4
1
5
1=Brown
2=White
3=Blue
4=Black
5=Gray
MQDEC2-515 5m(16.4ft)
MQDEC2-530 9m(29.5ft)
MQDEC2-550 15m(49.2ft)
MQDEC2-575 23m(75.44ft)
MQDEC2-5100 30.5m(100ft)
MQDEC2-506RA 2m(6.56ft)
RightAngle
32 Typ.
[1.26"]
30 Typ.
[1.18"]
ø 14.5 [0.57"]
M12 x 1

MQDEC2-515RA 5m(16.4ft)
MQDEC2-530RA 9m(29.5ft)
MQDEC2-550RA 15m(49.2ft)
MQDEC2-575RA 23m(75.44ft)
MQDEC2-5100RA 31m(101.68ft)
Button Map from RSD1 to Sensor
The sensor may be optionally connected to the Banner RSD1 remote display accessory. Refer to this table for the RSD1 button association
withyoursensor.
